Cailong

VMPET-GF series is designed for customers who need stronger bonding between the PET film and aluminum layer. The brochure lists two grades: VMPET-GF and VMPET-GF02.

Common substrate thickness is 10-100 μm, with width and length produced to customer requirements. The technical table provides reference values for 12 μm film.

VMPET-GF02 provides the higher listed adhesion and barrier level. Grade selection should be based on the required lamination strength, oxygen barrier, moisture barrier and downstream process.

• 12 μm reference thickness and 1.4 g/cm³ density for both grades.
• Aluminum-layer thickness: ≥ 2.0 OD for VMPET-GF and ≥ 1.9 OD for VMPET-GF02.
• Aluminum-layer adhesion: ≥ 2.0 N/15mm for VMPET-GF and ≥ 2.5 N/15mm for VMPET-GF02.
• OTR: ≤ 1.5 / ≤ 1.0 cc/m²·24h respectively, tested to ASTM D-3985.
• WVTR: ≤ 1.5 / ≤ 1.0 g/m²·24h respectively, tested to ASTM F-1249.
• Surface tension: ≥ 48 mN/m on the metallized side and ≥ 42 mN/m on the non-metallized side.
• Tensile strength ≥ 170 MPa in MD and TD.
• The brochure lists conformity with FDA, EU, REACH, RoHS and GB 4806.7 requirements.

• Flexible-packaging lamination where aluminum-layer adhesion is a key requirement.
• Packaging for electronics, cosmetics and metal products.
• Decorative materials, labels and stickers.
• Final adhesion, barrier, printing, lamination and sealing performance should be validated in the customer's package structure.

Important Notes:

The above data, obtained from our internal testing, is provided for reference only to assist customers in sample evaluation or product use.

The final performance of the product depends on specific production processes, and improper use may cause irreversible damage.

As equipment, processing condtions, and end-use requirements vary across manufacturers, our company shall only be responsible for the

performance of the film itself.

FAQ

What is high-adhesion metallized PET film mainly used for?

The existing page lists flexible-packaging lamination, electronics, cosmetics and metal-product packaging, decorative materials and labels.

What are the key characteristics of this film?

The page describes high aluminum-layer adhesion together with high and ultra-high barrier performance for food preservation and flavor retention.

What should buyers confirm before ordering?

Buyers should confirm the required product grade, aluminum-layer adhesion, OTR and WVTR requirements, thickness and intended lamination or packaging structure.
