Knotted polyester aluminized film
View details >Thermal Transfer PET Film features excellent physical and mechanical properties, small thickness tolerance, high transparency, good thermal stability, high heat resistance, low thermal shrinkage, good flexibility and excellent release performance, and is reusable.
Thermal Transfer PET Film features excellent physical and mechanical properties, small thickness tolerance, high transparency, good thermal stability, high heat resistance, low thermal shrinkage, good flexibility and excellent release performance, and is reusable.
1. Has excellent physical and mechanical properties;
2. Excellent thermal stability.
1. It can be used for laser, foil stamping and heat transfer printing materials;
2. It can also be used as a protective film, etc.



| 物性项目Item | 测试方法Testing Methods | 单位Units | 参考标准Standard | 典型值Typical Values | |||
| GB/T16958-2008 | |||||||
| 厚度Thickness | GB/T6672 | um | ─ | 12 | |||
| 雾度Haze | GB/T 2410 | % | ≤8.0 | 3 | |||
| 光度Gloss | GB/T 8807 | % | ≥100 | 110 | |||
| 密度Density | GB/T 1033 | g/cm³ | 1.4 | 1.4 | |||
| 热收缩率 Heat Shrinkage Rate | MD | 150℃*30min | % | ≤3.0 | 0.5 | ||
| TD | % | ≤3.0 | 0 | ||||
| 湿润张力Surface Tension | Corona | GB/T 14216-2008 | mN/m | ─ | 46 | ||
| Non-corona | ─ | 46 | |||||
| 拉伸强度Tensile Strength | MD | GB/T1040.3 | Mpa | ≥170 | 210 | ||
| TD | ≥170 | 205 | |||||
| 断裂伸长率Elongation at Break | MD | GB/T1040.3 | % | ≤200 | 130 | ||
| TD | ≤200 | 120 | |||||
| 摩擦系数Coefficient of Friction | dynamic | GB/10006 | ─ | ≤0.55 | 0.35 | ||
| static | ─ | ≤0.65 | 0.4 | ||||
Important Notes:
The above data, obtained from our internal testing, is provided for reference only to assist customers in sample evaluation or product use.
The final performance of the product depends on specific production processes, and improper use may cause irreversible damage.
As equipment, processing condtions, and end-use requirements vary across manufacturers, our company shall only be responsible for the
performance of the film itself.
